BA118C Manual Angle Broom With Polypropylene/Wire Bristles
Specifications
| Brush Diameter | 32.1 in |
| Brush Speed at Maximum Flow | 199 rpm |
| Drive Method | Direct Drive |
| Height | 36.1 in |
| Interface Type | Skid Steer Coupler |
| Length | 68.5 in |
| Motor Displacement | 24.7 in³/rev |
| Optimal Hydraulic Flow | 42-86 L/min (11-23 gpm) |
| Optimal Hydraulic Pressure | 145-235 bar (2100-3400 psi) |
| Optional Hood Extension | 39.7 lb |
| Overall Width | 103.8 in |
| Overall Width - Angled (± 30 Degrees) | 98.7 in |
| Required Hydraulics | Standard Flow |
| Sweeping Width | 83.4 in |
| Sweeping Width - Angled (± 30 Degrees) | 72.8 in |
| Weight | 906.1 lb |
