XQ570 Tier 4 Final – 455 ekW (568 kVA)

XQ570 Tier 4 Final – 455 ekW (568 kVA)

568 kVA Mobile Diesel Generator Set

More Comfort – More Performance – More Versatility

  • Flexible Two-way valve and external fuel ports

    Easily switch between onboard and external fuel source for extended run times

  • Generator Set Mounted EMCP 4.4 Controller

    Provides power metering, protective relaying, engine & generator control & monitoring and capability to run up to 8 units in parallel

  • Standard 500 Hour oil change intervals

    Maximizes run time before routine service is required

Generator Set

Frequency 60 Hz
Rating Prime 455 ekW (568 kVA)
Rating Standby 500 ekW (625 kVA)
Voltage 120 - 600V

Engine

Engine Cat C18
Fuel Diesel

Dimensions

Height - Without Trailer 102 in
Length - Without Trailer 240 in
Weight with Lube Oil and Coolant, Without Trailer 24125 lb
Width - Without Trailer 96 in

Fuel Consumption

100% Load 60Hz 33.2 gal/hr
100% Load 60Hz 35.9 gal/hr
50% Load 60Hz 19 gal/hr
50% Load 60Hz 20.5 gal/hr
75% Load 60Hz 26.2 gal/hr
75% Load 60Hz 28.3 gal/hr

Noise rating (with enclosure)

Sound Power @ 7 meters (23 feet) @ All Ratings 74 dB(A)

Download resources

XQ570 Rental Genset Spec Sheet
Cat Gensets Rating Guide
