XQ230 Rental Power

XQ230 Rental Power

228 kVA Mobile Diesel Generator Set

More Comfort ‚Äď More Performance ‚Äď More Versatility

  • Environmentally friendly 110% Battery isolator switch

    Eliminates battery draindown when generator set is not in operation

  • Flexible Two-way valve and external fuel ports

    Easily switch between onboard and external fuel source for extended run times

  • Power Distribution Three-position switch for easy selection of desired output

    Eliminates the need for reconnection to meet on-site requirements

Generator Set

Frequency 60 Hz
Rating Prime 182 ekW (228 kVA)
Rating Standby 200 ekW (250 kVA)
Voltage 120 - 600V

Engine

Engine Cat C7.1
Fuel Diesel

Dimensions

Height - Without Trailer 78.5 in
Length - Without Trailer 162.2 in
Weight with Lube Oil and Coolant, Without Trailer 8432 lb
Width - Without Trailer 62.8 in

Fuel Consumption

100% Load 60Hz 14.7 gal/hr
50% Load 60Hz 7.4 gal/hr
75% Load 60Hz 10.8 gal/hr

Noise rating (with enclosure)

Sound Power @ 7 meters (23 feet) @ All Ratings 72 dB(A)

Download resources

XQ230 Rental Generator Set Spec sheet
Cat Gensets Rating Guide
