C32 (60 Hz)

C32 (60 Hz)

830 - 1250 ekW Diesel Generator Set

More Comfort ‚Äď More Performance ‚Äď More Versatility

  • Saves up to 8% installed space

    Requires less space for installation

  • Weighs 28% less

    Reduced amount of structural support required

  • Full Power up to 50¬įC Ambient

    Provides full power even on hottest days of the year

Generator Set Specifications

Duty Cycle Standby, Mission Critical, Prime, Continuous
Emissions/Fuel Strategy Low Fuel, Tier 2 Nonroad Stds
Frequency 60 Hz
Maximum Rating 1250 ekW
Minimum Rating 830 ekW
Speed 1800 rpm
Voltage 220 to 4160 Volts

Engine Specifications

Aspiration TA
Bore 5.71 in
Compression Ratio 15.0:1
Displacement 1958.86 in³
Engine Model C32 TA, V-12, 4-Stroke Water-Cooled Diesel
Fuel System MEUI
Governor Type Adem‚ĄĘA4
Stroke 6.38 in

Generator Set Dimensions

Dry Weight - Genset (maximum) 16755 lb
Dry Weight - Genset (minimum) 14700 lb
Height - Maximum 86.4 in
Height - Minimum 85.1 in
Length - Maximum 172.7 in
Length - Minimum 164 in
Width - Maximum 87.7 in
Width - Minimum 66.3 in

Download resources

Electric Power Ratings Guide
C32, 60 Hz, 1000 ekW Standby/MC, 910 ekW Prime, 830 ekW Cont., Low Fuel Consumption Spec Sheet
C32, 60 Hz, 1000 ekW Standby/MC, 910 ekW Prime, 830 ekW Cont., U.S. EPA Certified for Emergency Stationary Applications (Tier 2) Spec Sheet
C32, 60 Hz, 1250 ekW Standby/MC, 1136 ekW Prime, Low Fuel Consumption Spec Sheet
C32, 60 Hz, 1250 ekW Standby/MC, 1136 ekW Prime, U.S. EPA Certified for Emergency Stationary Applications (Tier 2) Spec Sheet
C27-C32 GC NA Enclosure data sheet
