Delivering Optimized Cost Per Ton
More Comfort – More Performance – More Versatility
-
Payload Without Compromise
Nominal rated payload delivered for all truck configurations — including attachments
-
Up to 8% Increased Torque on Demand
Unlock maximum drivetrain capability with Cat TorqueBoost technology
-
Increased Tire Life and TKPH
327-ton (360-ton) payload matched with 59/80 R63 tires lowers costs and improves tire performance
Engine
| Bore | 6.9 in |
| Displacement | 5187 in³ |
| Emissions Rating | Fuel Optimized |
| Engine Model | Cat® C175-16 |
| Gross Power - SAE J1995 | 3500 hp |
| Net Power - SAE J1349 | 3405 hp |
| Note (1) | Net Power advertised is the power available at the flywheel when the engine is equipped with air intake system, exhaust system, and alternator. |
| Note (2) | U.S. EPA Tier 4 Final / EU Stage V available for applicable markets. |
| Note (3) | Additional fuel optimized selectable power ratings: 2312 kW / 3,100 hp |
| Rated Speed | 1800 r/min |
| Stroke | 8.7 in |
Weights - Approximate
| Body Weight Range | 38 833 – 42 907 kg (85,611 – 94,594 lb) |
| Chassis Weight | 448415 lb |
| Nominal Rated Payload | 360 ton (US) |
| Note (1) | Consult your tire manufacturer for maximum tire load. |
| Note (2) | Chassis weight with full fuel and fluids, standard & mandatory attachments, hoist, body mounting group, rims, and tires. |
| Note (3) | Refer to Cat Mining Truck 10/10/20 Overload Policy (AEXQ0250) for maximum gross machine weight limitations |
| Rated Gross Machine Weight | 1270000 lb |
Weight Distributions - Approximate
| Front Axle - Empty | 47 % |
| Front Axle - Loaded | 33 % |
| Note | Weight distributions optimized with Cat body. |
| Rear Axle - Empty | 53 % |
| Rear Axle - Loaded | 67 % |
AC Drive System
| Controls | Cat IGBT Inverter Technology, air cooled, pressurized cabinet with filtration |
| Cooling System | Cat variable speed, hydraulically driven cooling system |
| Generator/Alternator | Cat brushless, engine mounted, dual bearing |
| Top Speed - Loaded | 40 mile/h |
| Total Reduction Ratio | 35:01:00 |
| Wheel Motor | Cat AC induction, rear axle mounted |
Tires
| Note (1) | Quick Change Rims optional. |
| Note (2) | Caterpillar recommends the customer evaluate all job conditions and consult tire manufacturer for proper tire selection and TKPH (TMPH) capabilities. |
| Rims | 44" x 63" |
| Standard Tires | 59/80 R63 |
Braking System
| Dynamic Retarding Power - Continuous | 5480 hp |
| Front Wet Disc Brake Surface Area | 20378 in² |
| Load Brake | Rear service brakes |
| Note | Anti-Lock Brake System (ABS) optional with CMD package |
| Parking Brake | Four-corner, Multi-disc, Spring Applied, Hydraulically Released |
| Rear - Wet Disc Brake Surface Area | 30750 in² |
| Service Brakes | Four-Corner, Wet Disc, Oil Cooled, Hydraulically Actuated |
| Standards | Service and Secondary: ISO 3450:2011 |
Capacity - HE Body - 100% fill factor
| Heaped (SAE 2:1) | 186-237 m³ (243-310 yd³) |
| Note | Consult your local Cat dealer for body recommendations. |
| Struck | 97-153 m³ (127-200 yd³) |
Body Hoists
| Body Lower Time - Float | 22 s |
| Body Power Down- High Idle | 17.5 s |
| Body Raise Time - High Idle | 21 s |
| Note (1) | Twin, two-stage hydraulic cylinders mounted outside main frame; double-acting cylinders in both stages. |
| Note (2) | Power raise in both stages; power down capability in both stages. |
| Note (3) | Automatic body-lower modulation reduces impact on frame. |
| Pump Flow - High Idle | 257.3 gal/min |
| Relief Valve Setting - Raise | 3029 psi |
| Type | Twin, two-stage hydraulic cylinders with snubbing valve. |
Suspension
| Effective Cylinder Stroke - Front | 4 in |
| Effective Cylinder Stroke - Rear | 2 in |
| Rear axle - Oscillation | +/- 5.32 degrees |
| Type | Self-contained nitrogen/oil cylinders, pin-to-pin mounting, top & bottom double shear clevis attachments |
Service Refill Capacities
| Cooling System | 211 gal (US) |
| Crankcase | 82 gal (US) |
| Diesel Exhaust Fluid Tank | 100 gal (US) |
| Final Drive - Each | 67 gal (US) |
| Front Wheels - Each | 7 gal (US) |
| Fuel Tank | 1300 gal (US) |
| Fuel Tank (Tier 4) | 1200 gal (US) |
| Grease Tank | 90 lb |
| Hydraulic System - Including Tank | 385 gal (US) |
| Hydraulic Tank | 296 gal (US) |
| Note (1) | DEF Tank only available for U.S. EPA Tier 4 Final / EU Stage V engine option |
Cab
| Air Conditioning | HFC - 134A refrigerant: 21,600 Btu/h |
| FOPS Standards | FOPS (Falling Objects Protective Structure) meets ISO 3449:2005 Level II for Operator and ISO 13459:2012 Level II for Trainer. |
| Heater / Defroster | 24600 Btu/h |
| Note | Ambient capabilities down to -15C (5F) for heater/defroster and up to 50C (122F) for air conditioning. |
| ROPS Standards (1) | ROPS (Rollover Protective Structure) meets ISO 3471:2008 for Operator and ISO 13459:2012 for Trainer. |
Sound
| Sound Standards | The operator sound pressure level, 75 dB(A), measured according to ISO 6394:2008 and ISO 6396:2008. |
Steering
| Note | Turning Diameter (ISO 7457:1997) |
| Steer Angle | 39 ° |
| Steering Standards | ISO 5010:2019 |
| Turning Diameter - Front | 106.3 ft |
Dimensions (Approximate)
| Centerline Front Tire Width | 23.06 ft |
| Centerline of Rear Dual Tire Width | 19.5 ft |
| Dump Clearance - Empty | 5.72 ft |
| Front Axle Clearance - Loaded | 2.81 ft |
| Front Canopy Height - Empty | 26.01 ft |
| Height - Top of ROPS | 22.05 ft |
| Inside Body Width | 29.44 ft |
| Loading Height - Empty | 23.85 ft |
| Note | Dimensions listed includes canopy deflectors |
| Outside Body/Canopy Width (without rock deflectors) | 31.62 ft |
| Overall Canopy Width (with rock deflectors) | 33.15 ft |
| Overall Height - Body Raised | 48.85 ft |
| Overall Length | 51.44 ft |
| Overall Tire Width - Empty | 30.27 ft |
| Rear Axle - Tail | 16.07 ft |
| Rear Axle Clearance - Loaded | 2.8 ft |
| Wheel Base | 21.9 ft |
