Engine
|
Bore
|
6.7 in
|
|
Displacement
|
4766 in³
|
|
Emissions
|
U.S. EPA Tier 4 Final/EU Stage V or
U.S. EPA Tier 1 equivalent
|
|
Engine Model
|
Cat® 3516E
|
|
Engine Power - ISO 14396
|
1847 HP
|
|
Gross Power - SAE J1995
|
1870 HP
|
|
Net Power - SAE J1349 - High Ambient
|
1696 HP
|
|
Net Power - SAE J1349 - Standard Ambient
|
1739 HP
|
|
Note (1)
|
The power ratings apply when tested under the reference conditions for the specified standard.
|
|
Note (2)
|
The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner and muffler.
|
|
Note (3)
|
The gross power advertised is with the fan at maximum speed.
|
|
Peak Torque - 1,200 rpm - SAE J1995
|
8549 lb/ft
|
|
Stroke
|
8.5 in
|
|
Torque Rise
|
39%
|
Operating Specifications
|
Bucket Capacity Range
|
17.2-43.6 m3 (22.3-57 yd3)
|
|
Note
|
*Please contact your local dealer to determine if your application is suitable for this increased rated payload.
|
|
Operating Weight - High Lift
|
544457 lb
|
|
Operating Weight - Standard
|
540555 lb
|
|
Rated Payload - High Lift (Low to Moderate Digging Resistance)
|
55 ton (US)
|
|
Rated Payload - High Lift (Moderate to High Digging Resistance)
|
50 ton (US)
|
|
Rated Payload - Standard Lift (Low to Moderate Digging Resistance)
|
60 ton (US)
|
|
Rated Payload - Standard Lift (Moderate to High Digging Resistance)
|
50 ton (US)
|
Transmission
|
Direct Drive - Forward 1
|
Lock-up disables
|
|
Direct Drive - Forward 2
|
8.7 mile/h
|
|
Direct Drive - Forward 3
|
15.2 mile/h
|
|
Direct Drive - Reverse 1
|
Lock-up disables
|
|
Direct Drive - Reverse 2
|
9.6 mile/h
|
|
Direct Drive - Reverse 3
|
16.8 mile/h
|
|
Forward - 1
|
4.6 mile/h
|
|
Forward - 2
|
8 mile/h
|
|
Forward - 3
|
13.6 mile/h
|
|
Note
|
Travel speeds based on 58/85-57 tires.
|
|
Reverse - 1
|
5 mile/h
|
|
Reverse - 2
|
8.8 mile/h
|
|
Reverse - 3
|
14.9 mile/h
|
|
Transmission Type
|
Cat Planetary Power Shift
|
Hydraulic System - Lift/Tilt
|
Cylinders, Double Acting - Lift, Bore and Stroke
|
370 × 1713 mm (14.6 × 67.4 in)
|
|
Cylinders, Double Acting - Tilt, Bore and Stroke
|
310 × 1086 mm (12.2 × 42.8 in)
|
|
Lift/Tilt System - Circuit
|
Positive Flow Control
|
|
Lift/Tilt System - Pump
|
Variable Displacement Piston
|
|
Maximum Flow at 1,700 rpm Engine Speed
|
541 gal/min
|
|
Pilot System
|
Open Loop and Pressure Reducing
|
|
Relief Valve Setting - Lift/Tilt
|
5004 psi
|
Hydraulic Cycle Times
|
Dump
|
3.1 s
|
|
Lower Float Down
|
4.2 s
|
|
Rack Back
|
4.9 s
|
|
Raise
|
12.6 s
|
|
Total Hydraulic Cycle Time - Empty Bucket
|
23.5 s
|
Complete System Fill
|
Cooling System
|
138 gal (US)
|
|
Differential - Final Drives - Front
|
220 gal (US)
|
|
Differential - Final Drives - Rear
|
200 gal (US)
|
|
Engine Crankcase
|
76 gal (US)
|
|
Fuel Tank - Standard
|
856 gal (US)
|
|
Fuel Tank - With 24 hr Attachment
|
1414 gal (US)
|
|
Hydraulic Tank - Implement and Hydraulic Fan
|
270 gal (US)
|
|
Hydraulic Tank - Steering and Braking
|
100 gal (US)
|
|
Note
|
*Not available on Tier 4 Final/Stage V machines. Not available in all regions.
|
|
Oil Renewal System (ORS)*
|
20 gal (US)
|
|
Transmission
|
110 gal (US)
|
Axles
|
Front
|
Fixed
|
|
Oscillation Angle
|
9°
|
|
Rear
|
Trunnion
|
Cooling System
|
Ambient Capability Hydraulically Driven Demand Fan - High (Tier 1 equivalent)
|
131 °F
|
|
Ambient Capability Hydraulically Driven Demand Fan - High (Tier 4 Final)
|
127.4 °F
|
|
Ambient Capability Hydraulically Driven Demand Fan - Standard
|
109.4 °F
|
Sound Performance - Standard
|
Machine Sound Level (ISO 6395:2008)
|
119 dB(A)
|
|
Note
|
The measurement was conducted at 70 percent of the maximum engine cooling fan speed. Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.
|
|
Operator Sound Level (ISO 6396:2008) - Tier 1/EU Stage I Equivalent
|
72 dB(A)
|
Sound Performance - Suppression
|
Machine Sound Level (ISO 6395:2008)
|
117 dB(A)
|
|
Note
|
The measurement was conducted at 70 percent of the maximum engine cooling fan speed. Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.
|
|
Operator Sound Level (ISO 6396:2008) - Tier 1/EU Stage I Equivalent
|
71 dB(A)
|
Hydraulic System - Steering
|
Steering Cycle Times - High Idle
|
4.3 s
|
|
Steering Cycle Times - Low Idle
|
7.6 s
|
|
Steering System - Circuit
|
Pilot, Load Sensing
|
|
Steering System - Pump
|
Piston, Variable Displacement
|
|
Total Steering Angle
|
80 degrees
|
Dimensions - Standard Lift - Approximate
|
B-Pin Height - Maximum Lift
|
28.8 ft
|
|
Clearance at Maximum Lift
|
19.8 ft
|
|
Dump Angle at Maximum Lift
|
–50.0 degrees
|
|
Front Axle Centerline to Bucket Tip
|
21.9 ft
|
|
Ground to Bumper Clearance
|
4.4 ft
|
|
Ground to Center of Axles
|
6 ft
|
|
Ground to Lower Hitch Clearance
|
2.9 ft
|
|
Ground to Top of Exhaust Stacks
|
23.2 ft
|
|
Ground to Top of Hood
|
18.6 ft
|
|
Ground to Top of ROPS
|
23.4 ft
|
|
Maximum Overall Height - Bucket Raised
|
39.3 ft
|
|
Maximum Overall Length
|
64.6 ft
|
|
Note
|
Assumes loaded 58/85-57 tires, tires at a static loaded radius of 1830 mm (6 ft), 596-5330 26 m3 (34 yd3) bucket, 431-0064 HD tips.
|
|
Rack Angle at Maximum Lift
|
59.5 degrees
|
|
Rack Back Angle - Carry
|
47.7 degrees
|
|
Rack Back Angle - Ground Level
|
39.7 degrees
|
|
Reach - Maximum Lift
|
9.6 ft
|
|
Rear Axle - Centerline to Bumper
|
20.4 ft
|
|
Tread Width
|
14.1 ft
|
|
Wheel Base
|
22.3 ft
|
|
Width - Over Tires - With Bulge
|
18.8 ft
|
Dimensions - High Lift - Approximate
|
B-Pin Height - Maximum Lift
|
31.6 ft
|
|
Clearance at Maximum Lift
|
22.6 ft
|
|
Dump Angle at Maximum Lift
|
–50.0 degrees
|
|
Front Axle Centerline to Bucket Tip
|
24.2 ft
|
|
Ground to Bumper Clearance
|
4.4 ft
|
|
Ground to Center of Axles
|
6 ft
|
|
Ground to Lower Hitch Clearance
|
2.9 ft
|
|
Ground to Top of Exhaust Stacks
|
23.2 ft
|
|
Ground to Top of Hood
|
18.6 ft
|
|
Ground to Top of ROPS
|
23.4 ft
|
|
Maximum Overall Height - Bucket Raised
|
42.1 ft
|
|
Maximum Overall Length
|
66.9 ft
|
|
Note
|
Assumes loaded 58/85-57 tires, tires at a static loaded radius of 1830 mm (6 ft), 596-5330 26 m3 (34 yd3) bucket, 431-0064 HD tips.
|
|
Rack Angle at Maximum Lift
|
59.4 degrees
|
|
Rack Back Angle - Carry
|
53.5 degrees
|
|
Rack Back Angle - Ground Level
|
45 degrees
|
|
Reach - Maximum Lift
|
9.4 ft
|
|
Rear Axle - Centerline to Bumper
|
20.4 ft
|
|
Tread Width
|
14.1 ft
|
|
Wheel Base
|
22.3 ft
|
|
Width - Over Tires - With Bulge
|
18.8 ft
|
