Engine
|
Bore
|
5.4 in
|
|
Displacement
|
1649.5 inÂł
|
|
Emissions
|
U.S. EPA TIer 4 Final and EU Stage V emission standards or U.S. EPA Tier 2 and EU Stage II equivalent
|
|
Engine Model
|
C27 Cat®
|
|
Engine Power - ISO 14396
|
752 HP
|
|
Gross Power - SAE J1995
|
766 HP
|
|
Net Power - SAE J1349 - High Ambient
|
648 HP
|
|
Net Power - SAE J1349 - Standard Ambient
|
699 HP
|
|
Peak Torque - 1,200 rpm
|
2624 lb/ft
|
|
Rated Speed
|
1,800/min
|
|
Stroke
|
6 in
|
|
Torque Rise
|
18 %
|
Transmission
|
Direct Drive - Forward 1
|
Lock-up disabled
|
|
Direct Drive - Forward 2
|
8.5 mile/h
|
|
Direct Drive - Forward 3
|
15.2 mile/h
|
|
Direct Drive - Reverse 1
|
5.4 mile/h
|
|
Direct Drive - Reverse 2
|
9.6 mile/h
|
|
Direct Drive - Reverse 3
|
16.4 mile/h
|
|
Forward - 1
|
4.5 mile/h
|
|
Forward - 2
|
8.3 mile/h
|
|
Forward - 3
|
14.2 mile/h
|
|
Note
|
Travel speeds based on Michelin 45/65R39 LD D2**L5 tires.
|
|
Reverse - 1
|
4.9 mile/h
|
|
Reverse - 2
|
9.1 mile/h
|
|
Reverse - 3
|
15.5 mile/h
|
|
Transmission Type
|
Cat planetary power shift
|
Operating Specifications
|
Bucket Capacity Range
|
8.6 m³ – 10.0 m³ (11.25 yd³ – 13.0 yd³)
|
|
Cat Truck Match - High Lift
|
775-777
|
|
Cat Truck Match - Standard
|
773-775
|
|
Operating Weight
|
178517 lb
|
|
Rated Payload - High Lift
|
17.5 ton (US)
|
|
Rated Payload - Standard
|
17.5 ton (US)
|
Hydraulic System - Lift/Tilt
|
Cylinders, Double Acting - Lift, Bore and Stroke
|
235 mm Ă— 1287 mm (9.3 in Ă— 50.7 in)
|
|
Cylinders, Double Acting - Tilt, Bore and Stroke
|
292.1 mm Ă— 820 mm (11.5 in Ă— 32.3 in)
|
|
Lift/Tilt System
|
Variable displacement piston
|
|
Lift/Tilt System - Circuit
|
Positive flow control
|
|
Maximum Flow at 1,800 rpm (1)
|
240 gal/min
|
|
Pilot System
|
Open loop and pressure reducing
|
|
Relief Valve Setting - Lift/Tilt
|
4786 psi
|
|
Relief Valve Setting - Main
|
507 psi
|
Hydraulic Cycle Times
|
Dump
|
2.9 s
|
|
Lower
|
3.7 s
|
|
Lower Float Down
|
3.6 s
|
|
Rack Back
|
4.3 s
|
|
Raise
|
8.2 s
|
|
Total Hydraulic Cycle Time - Empty Bucket
|
13.8 s
|
Hydraulic System - Steering
|
Maximum Flow at 1,400 rpm
|
96.2 gal/min
|
|
Relief Valve Setting - Steering
|
5004 psi
|
|
Steering System - Circuit
|
Pilot, load sensing
|
|
Steering System - Pump
|
Piston, variable displacement
|
|
Total Steering Angle
|
70°
|
Air Conditioning System
|
Air Conditioning
|
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2.7 kg of refrigerant which has a CO2 equivalent of 3.861 metric tonnes (4.256 tons).
|
Axles
|
Front
|
Fixed
|
|
Oscillation Angle
|
8.5°
|
|
Rear
|
Trunnion
|
Service Refill Capacities
|
Cooling System
|
54.9 gal (US)
|
|
Differential - Final Drives - Front
|
71.6 gal (US)
|
|
Differential - Final Drives - Rear
|
68.9 gal (US)
|
|
Engine Crankcase
|
20 gal (US)
|
|
Fuel Tank
|
294.3 gal (US)
|
|
Hydraulic System Factory Fill
|
210 gal (US)
|
|
Hydraulic Tank - Implement and Hydraulic Fan
|
68.9 gal (US)
|
|
Hydraulic Tank - Steering and Braking
|
34.9 gal (US)
|
|
Note
|
All nonroad U.S. EPA Tier 4 diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) fuels containing 15 ppm (mg/kg) sulfur or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214. Cat DEO‑ULS™ or oils that meet the Cat ECF-3, API CJ‑4, and ACEA E9 specification are required. For further fluid specifications and guidelines, visit: http://parts.cat.com/cda/files/3244668/7/SEBU6250-19.pdf.
|
|
Transmission
|
29.1 gal (US)
|
Sound Performance - Standard
|
Machine Sound Level (ISO 6395:2008)
|
115 dB(A)
|
|
Operator Sound Level (ISO 6396:2008)
|
65.5 dB(A)
|
Sound Performance - Suppression
|
Machine Sound Level (ISO 6395:2008)
|
113 dB(A)
|
|
Operator Sound Level (ISO 6396:2008)
|
65.5 dB(A)
|
Buckets
|
Bucket Capacities
|
8.6 m³ – 10.0 m³ (11.25 yd³ – 13.0 yd³)
|
