Engine
|
Biodiesel Capability
|
Up to B20¹
|
|
Bore
|
4 in
|
|
Displacement
|
220 in³
|
|
Emissions
|
Meets U.S. EPA Tier 4 Final, EU Stage V, Japan 2014 emission standards.
|
|
Engine Model
|
Cat C3.6
|
|
Engine Power - ISO 14396
|
110 HP
|
|
Engine Power - ISO 14396 (DIN)
|
111 hp (metric)
|
|
Net Power - ISO 9249
|
108 HP
|
|
Net Power - ISO 9249 (DIN)
|
110 hp (metric)
|
|
Note (1)
|
Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system and alternator with engine speed at 2,400 rpm. Advertised power is tested per the specified standard in effect at the time of manufacture.
|
|
Note (2)
|
¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels.Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations“ (SEBU6250) for details. * Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).** Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels.
|
|
Stroke
|
5 in
|
Hydraulic System
|
Main System - Maximum Flow
|
276 l/min (73 gal/min)
|
|
Maximum Pressure - Equipment
|
5075 psi
|
|
Maximum Pressure - Swing
|
3770 psi
|
|
Maximum Pressure - Travel
|
5075 psi
|
Swing Mechanism
|
Maximum Swing Torque
|
25815 ft·lbf
|
|
Swing Speed
|
12 r/min
|
Weights
|
Operating Weight
|
34000 lb
|
Service Refill Capacities
|
Cooling System
|
4 gal (US)
|
|
DEF Tank
|
6 gal (US)
|
|
Engine Oil
|
2 gal (US)
|
|
Final Drive - Each
|
1 gal (US)
|
|
Fuel Tank Capacity
|
49 gal (US)
|
|
Hydraulic System - Including Tank
|
22.5 gal (US)
|
|
Hydraulic Tank
|
19 gal (US)
|
Dimensions
|
Boom
|
Reach 4.65 m (15'3")
|
|
Bucket
|
GD 0.53 m³ (0.69 yd³)
|
|
Counterweight Clearance
|
2.8 ft
|
|
Ground Clearance
|
1.4 ft
|
|
Handrail Height
|
9.3 ft
|
|
Length to Center of Rollers
|
9.9 ft
|
|
Shipping Height - Top of Cab
|
9.2 ft
|
|
Shipping Length
|
24.7 ft
|
|
Shipping Length - with Blade
|
26.5 ft
|
|
Stick
|
Reach R3.0 m (9'10")
|
|
Tail Swing Radius
|
5.1 ft
|
|
Track Gauge
|
6.5 ft
|
|
Track Length
|
12.3 ft
|
|
Transport Width
|
8.1 ft
|
Working Ranges & Forces
|
Boom
|
Reach 4.65 m (15'3")
|
|
Bucket
|
GD 0.53 m³ (0.69 yd³)
|
|
Bucket Digging Force - ISO
|
22180 lbf
|
|
Maximum Cutting Height
|
31.7 ft
|
|
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom
|
19 ft
|
|
Maximum Digging Depth
|
19.6 ft
|
|
Maximum Loading Height
|
23.6 ft
|
|
Maximum Reach at Ground Level
|
28.5 ft
|
|
Maximum Vertical Wall Digging Depth
|
16.9 ft
|
|
Minimum Loading Height
|
6.8 ft
|
|
Minimum Working Equipment Radius
|
7.3 ft
|
|
Stick
|
Reach R3.0 m (9'10")
|
|
Stick Digging Force - ISO
|
13330 lbf
|
Air Conditioning System
|
Air Conditioning
|
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.8 hg of refrigerant which has a CO2 equivalent of 1.144 metric tonnes.
|
