Engine
|
Emissions
|
U.S. EPA Tier 4 Final/EU Stage V/Korea Stage V
|
|
Engine Model
|
Cat C15
|
|
Net Power - ISO 9249 (DIN)
|
359 mhp
|
|
Net Power - ISO 9249/SAE J1349
|
354 HP
|
|
Note (1)
|
Net power at 1,900 rpm. Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator. Advertised power is tested per the specified standard in effect at the time of manufacture.
|
|
Note (2)
|
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) ** or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. ** Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).
|
|
Note (3)
|
Machine Build Number 21B
|
|
Power - Net
|
354 HP
|
Weights
|
Operating Weight
|
87600 lb
|
Transmission
|
Power Train
|
Fully Automatic 4-Speed Powershift
|
Service Refill Capacities
|
DEF Tank
|
6 gal (US)
|
|
Fuel Tank
|
165 gal (US)
|
Standard SU
|
Blade
|
Semi-Universal (SU)
|
|
Blade Capacity
|
13 yd³
|
|
Ground Pressure
|
13 psi
|
|
Operating Weight
|
88698 lb
|
|
Width of Standard Shoe
|
24 in
|
LGP
|
Blade
|
Semi-Universal (SU)
|
|
Blade Capacity
|
12.9 yd³
|
|
Ground Pressure
|
8 psi
|
|
Operating Weight
|
84906 lb
|
|
Width of Standard Shoe
|
38 in
|
Waste Handler
|
Blade
|
Semi-Universal (SU) Landfill
|
|
Blade Capacity
|
21 yd³
|
|
Ground Pressure
|
13 psi
|
|
Operating Weight
|
88206 lb
|
|
Width of Standard Shoe
|
24 in
|
LGP Waste Handler
|
Blade
|
Semi-Universal (SU) Landfill
|
|
Blade Capacity
|
27.9 yd³
|
|
Ground Pressure
|
8.8 psi
|
|
Operating Weight
|
93672 lb
|
|
Width of Standard Shoe
|
38 in
|
Air Conditioning System
|
Air Conditioning
|
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2.5 kg of refrigerant which has a CO2 equivalent of 3.575 metric tonnes.
|
