Weights
Maximum Operating Weight
|
28991 lb
|
Standard - Operating Weight
|
27557 lb
|
Static Linear Load
|
189 lb/in
|
Operating Specifications
Curb Clearance
|
28 in
|
Drum Offset
|
6 in
|
Ground Clearance
|
11.5 in
|
Standard Compaction Width
|
79 in
|
Engine
Engine Model
|
Cat C4.4
|
Gross Power
|
142 hp
|
Travel Speeds
High
|
8 mile/h
|
Low
|
4 mile/h
|
Dimensions
Height - With ROPS/FOPS
|
10 ft
|
Overall Length
|
15.5 ft
|
Overall Width
|
92 in
|
Wheel Base
|
11.25 ft
|
Vibratory System
Centrifugal Force per Drum - Maximum
|
24728 lb
|
Centrifugal Force per Drum - Minimum
|
7800 lb
|
Maximum Amplitude
|
0.038 in
|
Maximum Frequency
|
3800 VPM
|
Minimum Amplitude
|
0.012 in
|
Minimum Frequency
|
2520 VPM
|
Service Refill Capacities
Fuel Tank Capacity
|
66 gal (US)
|
Water Spray Tank Capacity
|
264 gal (US)
|
