Get a quote836 Landfill Compactor
Do More with Less
More Comfort – More Performance – More Versatility
-
IMPROVED PERFORMANCE
Improved operation with smoother directional shifts due to Cat locker differentials
-
ENHANCED TECHNOLOGY
Boost your productivity with standard technologies like Cat Compact with Pass Mapping and optional Cat Compact with Elevation Mapping
-
IMPROVED GUARDING
New features such as additional axle Duo-cone® seal guards, eyebrow guards, and new reversing fan guard help protect the machine from trash intake andother onsite hazards
Engine
| Bore | 5.71 in |
| Displacement | 1104.5 inÂł |
| Emissions | U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V and Japan 2014 or Brazil MAR-1, equivalent to China Nonroad Stage III/U.S. EPA Tier 3/ EU Stage IIIA |
| Engine Model | C18 |
| Engine Power - ISO 14396:2002 | 553 hp |
| Gross Power - SAE J1995:2014 | 562 hp |
| High Idle Speed | 2120 r/min |
| Low Idle Speed | 750 r/min |
| Maximum Altitude - Without Derating | 7500 ft |
| Net Power - ISO 9249:2007 | 502 hp |
| Net Power - SAE J1349:2011 | 496 hp |
| Note | Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator. |
| Peak Torque ( 1,400 rpm ) | 2275 lbf·ft |
| Rated Speed | 1900 rpm |
| Stroke | 7.2 in |
| Torque Rise | 52% |
Operating Specifications
| Maximum Operating Weight (Tier 3/Stage IIIA equivalent) | 125622 lb |
| Maximum Operating Weight (Tier 4 Final/Stage V) | 126364 lb |
| Operating Weight (Tier 3/Stage IIIA equivalent) | 123321 lb |
| Operating Weight (Tier 4 Final/Stage V) | 124063 lb |
Transmission
| Direct Drive - Forward 1 | 4.3 mile/h |
| Direct Drive - Forward 2 | 7.8 mile/h |
| Direct Drive - Reverse 1 | 4.6 mile/h |
| Direct Drive - Reverse 2 | 8.2 mile/h |
| Transmission Type | Planetary - Powershift - ECPC |
Hydraulic System - Lift
| Cylinders, Double Acting: Lift, Bore, Stroke | 137.9 mm x 1021 mm (5.5 in x 40.2 in) |
| Lift System - Circuit | Flow Sharing Implement; Pilot Operated LS Valve w/EH |
| Lift System - Pump | Variable displacement piston |
| Max Flow @ 2000 rpm | 79 gal/min |
| Pilot Relief Valve Setting | 551 psi |
| Pilot System | Variable displacement piston |
| Relief Valve Setting - Lift | 4206 psi |
Hydraulic System - Steering
| Max Flow @ 2000 rpm | 79 gal/min |
| Relief Valve Setting - Steering | 3495 lb/in² |
| Steering Cycle Times - High Idle | 3.9 s |
| Steering Cycle Times - Low Idle | 6.4 s |
| Steering System - Circuit | Flow Sharing Implement; Pilot, load sensing |
| Steering System - Pump | Piston – Variable Displacement |
| Total Steering Angle | 86 |
Service Refill Capacities
| Cooling System - Tier 3/Stage IIIA Equivalent | 37.2 gal (US) |
| Cooling Systems - Tier 4 Final/EU Stage V | 40 gal (US) |
| Diesel Exhaust Fluid Tank | 9 gal (US) |
| Differential - Final Drives - Front | 49 gal (US) |
| Differential - Final Drives - Rear | 50 gal (US) |
| Engine Crankcase | 16 gal (US) |
| Fuel Tank | 209 gal (US) |
| Hydraulic System - Implement/Steering | 46.2 gal (US) |
| Hydraulic Tank Only | 27.2 gal (US) |
| Note | - All nonroad Tier 4 Final/Stage V diesel engines are required to use: - Ultra low sulfur diesel (ULSD) fuels containing 15 ppm (mg/kg) for EPA and 10 ppm (mg/kg) for EU sulfur or less. Biodiesel blends up to B20 are acceptable when blended with 15 ppm (mg/kg) sulfur or less ULSD and when the biodiesel feedstock meets ASTM D7467 specificiations. - Cat DEO-ULS™ or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specifications are required. - Diesel exhaust fluid (DEF) that meets all requirements defined in ISO 22241-1:2006. |
| Transmission | 21.9 gal (US) |
Air Conditioning System
| Air Conditioning | • The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. • If equipped with R134a (Global Warming Potential = 1430), the system contains 1.4 kg (3.1 lb) of refrigerant which has a CO2 equivalent of 2.002 metric tonnes (2.206 tons). |
Axles
| Front | Planetary – Fixed |
| Oscillation Angle | ±6° |
| Rear | Planetary – Oscillating |
Braking System
| Parking Brake | Spring Applied, Hydraulic Released |
| Service Brakes | Multi Disc Wet (Enclosed) 2 WHL |
Sound Performance - Tier 4 Final/EU Stage V
| Machine Sound Level (ISO 6395:2008) - Standard | 111 dB(A) |
| Machine Sound Level (ISO 6395:2008) - Suppression | 109 dB(A) |
| Note (1) | The operator sound pressure level was measured according to the test procedures and conditions specified in ISO 6396:2008. The measurements are conducted at 70% of the maximum engine cooling fan speed. |
| Note (2) | Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment. |
| Note (3) | The machine sound power level was measured according to the test procedures and conditions specified in ISO 6395:2008. The measurements are conducted at 70% of the maximum engine cooling fan speed. |
| Operator Sound Level (ISO 6396:2008) - Standard | 72 dB(A) |
| Operator Sound Level (ISO 6396:2008) - Suppression | 72 dB(A) |
Sound Performance - Tier 3 / Stage IIIA
| Machine Sound Level (ISO 6395:2008) - Standard | 112 dB(A) |
| Machine Sound Level (ISO 6395:2008) - Suppression | 110 dB(A) |
| Note (1) | The operator sound pressure level was measured according to the test procedures and conditions specified in ISO 6396:2008. The measurements are conducted at 70% of the maximum engine cooling fan speed. |
| Note (2) | Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment. |
| Note (3) | The machine sound power level was measured according to the test procedures and conditions specified in ISO 6395:2008. The measurements are conducted at 70% of the maximum engine cooling fan speed. |
| Operator Sound Level (ISO 6396:2008) - Standard | 72 dB(A) |
| Operator Sound Level (ISO 6396:2008) - Suppression | 72 dB(A) |
Dimensions (Approximate)
| Centerline of Rear Axle to Rear Compactor Guard | 11.3 ft |
| Ground Clearance to Bottom of Bumper | 3.2 ft |
| Ground Clearance to Hitch | 2.1 ft |
| Ground Clearance to Transmission Guard | 2.1 ft |
| Height - Cab Roof | 14.1 ft |
| Height - Top of Exhaust Pipe | 15.1 ft |
| Height - Top of Hood | 11.3 ft |
| Height to Top of Air Conditioning Condenser | 15.2 ft |
| Height to Top of Beacon | 15.2 ft |
| Hitch to Centerline of Front Axle | 7.5 ft |
| Overall Machine Length with Semi U-Blade | 35.8 ft |
| Wheel Base | 14.9 ft |
| Width over Drums | 14 ft |
| Width over Front Striker Bars | 12.9 ft |
| Width over Platform | 10.5 ft |
| Width over Rear Striker Bars | 12.9 ft |
Straight Blade
| Capacity | 25.9 ydÂł |
| Digging Depth | 1.2 ft |
| Ground Clearance | 5.7 ft |
| Height | 7.4 ft |
| Height of Cutting Edge | 3.7 ft |
| Overall Width | 17 ft |
| Total Operating Weight | 123000 lb |
| Turning Radius - Inside of Wheels | 11.9 ft |
| Turning Radius – Outside Corner of Blade | 28.7 ft |
| Weight | 6894 lb |
Semi U-Blade
| Capacity | 29.3 ydÂł |
| Digging Depth | 1.2 ft |
| Ground Clearance | 5.7 ft |
| Height | 7.5 ft |
| Height of Cutting Edge | 4.1 ft |
| Overall Width | 17.4 ft |
| Total Operating Weight | 124063 lb |
| Turning Radius – Inside of Wheels | 11.9 ft |
| Turning Radius – Outside Corner of Blade | 28.9 ft |
| Weight | 7963 lb |
U-Blade
| Capacity | 33.6 ydÂł |
| Digging Depth | 3.1 ft |
| Ground Clearance | 3.9 ft |
| Height | 7.2 ft |
| Height of Cutting Edge | 4.1 ft |
| Overall Width | 17.4 ft |
| Total Operating Weight | 123785 lb |
| Turning Radius – Inside of Wheels | 11.9 ft |
| Turning Radius – Outside Corner of Blade | 28.8 ft |
| Weight | 7696 lb |
Wheels
| Chopper Tips (Weight Group) | 28404 lb |
| Combination Tips (Weight Group) | 28250 lb |
| Diamond Tips Weight (Group) | 32659 lb |
| Drum Diameter | 69.7 in |
| Drum Width | 55.1 in |
| Feet Per Row | 8 |
| Feet Per Wheel | 40 |
| Outside Diameter | 83.8 in |
| Outside Diameter - Diamond | 84.3 in |
| Paddle Tips - Weight (Group) | 272227 lb |
| Plus Tips - Weight (Group) | 29784 lb |
| Replaceable | Weld on |
| Tip Height | 179 mm |
| Tip Height - Diamond | 7.25 in |
| Width Over Drums | 4280 mm |
