PM312 Track Undercarriage Cold Planer

PM312 Track Undercarriage Cold Planer

Mill with precision

Get a quote

More Comfort ‚Äď More Performance ‚Äď More Versatility

  • Comfortable Operation

    An ergonomically adjustable work area puts intuitive controls at your fingertips for operation while seated or standing. A 14-button ground-level keypad and optional display gives supporting personnel access to numerous machine controls.

  • Milling Precision

    Integrated technology and Cat System K rotors help achieve excellent cutting patterns and profiles. Cat track undercarriages offer smooth operation and a balance between traction, speed and maneuverability.

  • Low Cost of Ownership

    Maintenance-free track components and extended service intervals not only reduce downtime but decrease the amount of labor needed and parts replaced over the life of the machine.

Cutting System

Maximum Milling Depth 13 in
Milling Width 48.2 in
Number of Bits 106
Rotor Speeds 97 / 109 / 121 rpm

Power Train

Engine C9.3B
Maximum Milling Speed 108 ft/min
Maximum Travel Speed 3.4 mile/h
Rated Power 343 HP

Weights

Operating Weight 47407 lb
Transport Weight 46506 lb

Dimensions

Conveyor Swing 60 degrees from center
Height - Canopy 12.3 ft
Maximum Truck Clearance 15.42 ft
Minimum Left Cutting Radius 13.58 ft
Minimum Right Cutting Radius 6.3 ft
Operating Length - Conveyor Up 36.45 ft
Operating Width 8.33 ft
Transport Height 9.84 ft
Transport Length 30.58 ft
Transport Width 8.33 lb/in

Service Refill Capacities

Cooling System 16.9 gal (US)
Diesel Exhaust Fluid (DEF) Tank 12.4 gal (US)
Engine Oil 7.9 gal (US)
Fuel Tank 137.9 gal (US)
Hydraulic Tank 14.5 gal (US)
Water Spray System Tank 332.9 gal (US)
