SE60 V Screed

SE60 V Screed

Low Profile Stability

Get a quote

More Comfort – More Performance – More Versatility

  • High Quality Paving

    The low-profile design optimizes visibility for good operational control.

  • Simple Operation

    Intuitive controls and an optional remote pendent enable simple operation.

  • Advanced Technology

    The advanced screed plate heating system delivers job site efficiency with a fast 15 minute heat-up time.

Weights

Standard Weight 7826 lb

Operating Specifications

Crown Range -4% to +10%
Extender Height Range +50 mm to -20 mm
Extender Slope Range -3% to +10%
Heating Time - Maximum Width 25 minutes
Heating Time - Standard Width 15 minutes
Maximum Paving Depth 12 in
Maximum Paving Width 24.5 ft
Standard Paving Range 3.0 - 6.0 m (9' 10" - 19' 6"')
Vibratory Speed Range 0 - 3000 rpm

Dimensions

Length - Front to Back, Endgates Attached 94 in
Length - Front to Back, Endgates Removed 68 in
Screed Plate Width - Front to Back 16 in
