Get a quoteAP555
More Flexibility
More Comfort – More Performance – More Versatility
-
Increased Performance
More performance is delivered with increased feeder system capability, more power, and hopper insert capability
-
Simple Operation
The dual sliding stations, easy-viewing display, and unobstructed visibility to the hopper combine to simplify operation.
-
More Flexibility
Configurable screed designs, optimized weight and width, and the mobil-trac undercarriage design provides contractors with excellent flexibiity.
Dimensions
| Operating Length | 19.25 ft |
| Operating Width | 10.75 ft |
| Overall Height | 10.75 ft |
| Paving Range with SE47 FM | 2.4 m - 6.1 m (8' - 20') |
| Paving Range with SE47 V | 2.4 m - 6.2 m (8' - 20' 6") |
| Transport Height | 825 ft |
| Transport Length | 18.5 ft |
| Transport Width | 8.5 ft |
| Truck Entry Height | 22 in |
Engine
| Engine Model (1) | Cat C4.4 |
| Engine Power (1) | 148 hp |
Operating Specifications
| Maximum Paving Speed | 200 ft/min |
| Maximum Throughput Capacity | 1100 ton(US)/h |
| Maximum Travel Speed | 7 mile/h |
Weights
| Operating weight with SE47 FM | 33689 lb |
| Operating weight with SE47 V | 33448 lb |
| Shipping Weight - Paver Only | 26993 lb |
Service Refill Capacities
| Cooling System - Total | 6.3 gal (US) |
| DEF Tank | 5 gal (US) |
| Fuel Tank | 53 gal (US) |
| Hydraulic Oil Tank | 32 gal (US) |
| Washdown Spray Tank | 8.5 gal (US) |
