Dimensions
|
Operating Length
|
22.3 ft
|
|
Operating Width
|
10.8 ft
|
|
Overall Height
|
12.25 ft
|
|
Paving Range with SE60 FM
|
3.0 m - 7.8 m (10' - 25' 6")
|
|
Paving Range with SE60 V
|
3.0 m - 7.65 m (9' 10" - 25')
|
|
Paving Range with SE60 V XW
|
3.0 m - 10 m (10' - 33')
|
|
Paving Range with SE60 VT XW
|
3.0 m - 10 m (10' - 33')
|
|
Transport Height
|
9.7 ft
|
|
Transport Length
|
21.9 ft
|
|
Transport Width
|
9.8 ft
|
Engine
|
Engine Model (1)
|
Cat C7.1
|
|
Engine Power (1)
|
225 HP
|
Operating Specifications
|
Inside Turn Radius
|
1.5 ft
|
|
Maximum Paving Speed
|
210 ft/min
|
|
Maximum Paving Speed - With Tamper Bar Screed
|
82 ft/min
|
|
Maximum Throughput Capacity
|
1602 ton(US)/h
|
|
Maximum Travel Speed
|
9 mile/h
|
Weights
|
Operating weight with SE60 FM
|
45352 lb
|
|
Operating weight with SE60 V
|
45087 lb
|
|
Operating weight with SE60 V XW
|
46573 lb
|
|
Shipping Weight - Paver Only
|
36800 lb
|
Service Refill Capacities
|
Cooling System
|
12 gal (US)
|
|
DEF Tank
|
5 gal (US)
|
|
Fuel Tank Capacity
|
92 gal (US)
|
|
Hydraulic Oil Tank
|
58 gal (US)
|
|
Washdown Tank
|
7.9 gal (US)
|
