Get a quote735 Bare Chassis Articulated Truck
Customization to Work for Your Application.
More Comfort – More Performance – More Versatility
-
UP TO 50% LESS OPERATOR INPUT
A uniquely combined hoist and transmission lever allows for easy operation which suits a wide range of operator experience.
-
IMPROVED OPERATOR COMFORT
Quieter, more spacious cab with improved visibility helps operators work more productively throughout the day.
-
22% REDUCTION IN UNLADEN WEIGHT
Deliver more productivity while using less fuel in any size application.
Engine
| Bore | 5.1 in |
| Displacement | 736 in³ |
| Engine Model | Cat® C13 |
| Engine Model - U.S. EPA Tier 4 Final/EU Stage IV/Japan 2014 (Tier 4 Final)/Korea Tier 4 Final | Cat® C13 |
| Gross Power - SAE J1995:2014 | 434 hp |
| Net Power - ISO 14396 | 447 hp |
| Net Power - SAE J1349:2011 | 424 hp |
| No Engine De-rating Required Below | 12500 ft |
| Peak Engine Torque Gross (SAE J1995) | 1614 lb/ft |
| Peak Engine Torque Net (SAE J1349) | 1597 lb/ft |
| Peak Engine Torque Speed | 1200 r/min |
| Stroke | 6.2 in |
Wheel Base Length
| Long Wheel Base | 215.2 in |
| Standard Wheel Base | 156.7 in |
Weights
| Rated Payload | 43.1 ton (US) |
Transmission
| Forward - 1 | 5 mile/h |
| Forward - 2 | 9 mile/h |
| Forward - 3 | 14 mile/h |
| Forward - 4 | 22 mile/h |
| Forward - 5 | 30 mile/h |
| Forward - 6 | 35 mile/h |
| Reverse - 1 | 6 mile/h |
Service Refill Capacities
| Cooling System | 21.9 gal (US) |
| DEF Tank | 5.3 gal (US) |
| Engine Crankcase | 10 gal (US) |
| Final Drives/Differential | 33 gal (US) |
| Fuel Tank | 108.8 gal (US) |
| Hydraulic System | 29.1 gal (US) |
| Output Transfer Gear Box | 5.5 gal (US) |
| Transmission | 12.3 gal (US) |
Sound Levels
| Interior Cab | 72 dB(A) |
Standards
| Brakes | ISO 3450:2011 |
| Cab - FOPS | ISO 3449:2005 Level II |
| Cab - ROPS | ISO 3471:2008 |
| Steering | ISO 5010:2019 |
Steering
| Lock to Lock | 4.75 seconds at 60 rpm |
Turning Circle
| Note | Dimensions are for machines equipped with 750/65 R25 tires. |
| Turning Dimensions - Aisle Width | 212 in |
| Turning Dimensions - Clearance Radius | 318 in |
| Turning Dimensions - Inside Radius | 149 in |
| Turning Dimensions - SAE Turning Radius | 294 in |
| Turning Dimensions - Steer Angle - Left/Right | 45° |
